Features
1).Low Insertion Loss.
2).Low PDL.
3).High Return Loss.
4).Uniform Power Splitting.
5).Wide Operating Wavelength: 1260-1650nm
6).Wide Operating Temperature: -40°C - 85°C
Application
1.Fiber Optic CATV
2.Fiber to home(FTTH)
3.Passive Optical Networks(PON)
4.Local Areal Networks(LAN)
5.Fiber communication systems
Specifications
| Operating wavelength range(nm) | 1260nm-1650nm | ||||
|---|---|---|---|---|---|
| Port Configuration | 1 x 4 | 1 x 8 | 1x16 | 1x32 | 1X64 |
| Max. Insertion Loss(dB)* | ≤7.3 | ≤10.6 | ≤13.8 | ≤16.5 | ≤21 |
| Loss Uniformity(dB)* | ≤0.5 | ≤0.8 | ≤1.0 | ≤1.5 | ≤2.7 |
PackageType | Customer Specify | ||||
PDL(dB)* | ≤0.2 | ≤0.2 | ≤0.2 | ≤0.2 | ≤0.3 |
| Return Loss (dB)* | ≥50 | ||||
| Directivity (dB)* | ≥55 | ||||
| Storage Temperature (°C) | -40~85 | ||||
| Operating Temperature(°C) | -40~85 | ||||
| Fiber Type | SMF-28 | ||||
| Connector Type | Customer specified | ||||
Note: All measurements were done at room temperature, and specifications exclude connectors
Ordering Information
| PLCS | Port Type | Cable Type | Fiber Length | Connector Type | Package Style |
|---|---|---|---|---|---|
PLC Splitter | 1*4 1*8 1*16 1*32 1*64 2*32 Others Specify | 0.25mm Bare fiber Ribbon Fiber Fan-out with 0.9mm Loose Tube 2.0mm Cable 3.0mm Cable | 1 meter 2 meter 3 meter Others specify | FC/APC FC/PC SC/APC SC/PC ST/UPC LC/APC Others Specify | Stainless steel sleeve Plastic Module 19’’ 1U Rack Mount Others Specify |
